Bargraph	√	×	×	×	×
Full 270ºbar-graph	√	×	×	×	×
% markers	√	×	×	×	×
Display
Type	Rich OLED	LED	LED	LCD	7-segment
Colour display	√	×	×	×	×
sector colours to display safety bands	√	×	×	×	×
sectors configurable?	√	×	×	×	×
Relay status	√	√	√	√	√
Relay setting details	√	×	×	√	√
Display scroll to show different relay values	√	×	×	×	×
Power Save options available ?	√	×	×	×	×
Switching
Switch type	SPDT	PNP/NPN	PNP/NPN	SPDT	SPDT
Separate relay to drive end element needed?	×	√	√	×	×
Upper Lower limits configurable?	√	√	√	√	√
Manual reset facility	√	×	×	√	×
Electrical rating	5A, 250VAC	×	×	100 mA, 8-50VDC	10A 250VAC
Number of switching outputs	4	2	Unclear	1	1
Can there be a time delay on upper and lower limits?	√	×	×	√	×
Output
current analogue output ?	√	√	√	×	√
Voltage analogue output ?	√	×	×	×	×
Is output configurable (20 – 4 mA / 0 – 20 mA)?	√	×	×	×	×
Are outputs independently configurable?	√	×	×	×	×
Can Zero span be adjusted?	√	×	×	×	×
Can Zero span of current o/p be different than voltage o/p?	√	×	×	×	×
Datalogging facility
Available?	√	×	×	×	×
Minimum scan interval?	1 s	×	×	×	×
Maximum scan interval?	24 hr	×	×	×	×
Can data be extracted for a day remotely?	√	×	×	×	×
Amount of data storage?	10 years	×	×	×	×
Modes
Can it be configured for hydro static level parameter?	√	×	×	×	×
